    140 x 150 x 86 mm Desktop Power Supply Unit Durable With Long Service Life

    Ask Lasest Price
    Brand Name : OEM
    Model Number : RPD600-50ERN
    Price : Negotiable
    Payment Terms : T/T, Western Union, Paypal
    Supply Ability : Negotiable
    Delivery Time : Negotiable
    • Product Details
    • Company Profile

    140 x 150 x 86 mm Desktop Power Supply Unit Durable With Long Service Life

    80 PLUS power supply 600w Desktop PSU RPD600-50ERN


    Feature

    • Worldwide Input Voltage 100Vac-240Vac
    • Active PFC Within 0.99 Power Factor Correction
    • Quad 12V Rails To Fulfill System Protection Demand
    • Own Patent IC To Offer High Performance And Efficiency
    • 12cm Fan Provide Ultra Silent User Environment

    PC PSU Introduction

    • Dimension 140 (L) x 150 (W) x 86 (H) mm
    • Output Wattage 600W
    • Efficiency 85% 88% 85%


    The PC PSU DESCRIPTION


    This specification describes a 600 watts power supply. With 5 output, and remote ON/OFF control for ATX-12V system and a “Power factor correction (active PFC)” circuit at 100V-240Vac.


    APPLICATION: Desktop


    WATTAGE: 600W


    DIMENSION : 140mm(L) x 150mm(W) x 86mm(H)



    PRODUCT HIGHLIGHT


    • Efficiency Level: 80PLUS Silver
    • Erp Lot: <0.5W
    • Input Voltage: 100~240Vac

    INPUT SPECIFICATION


    Input Range: 100-240 Vac

    Input Frequency: 47-63 Hz

    Input Current: 9Amp (maximum) at 100-

    127Vrms/ 60 Hz 4.5Amp (maximum) at 200-240 Vrms/ 50 Hz.



    OUTPUT SPECIFICATION


    Output Rise Time: +3.3V 20mS (maximum)

    +5V 20mS (maximum)

    +12V 20mS (maximum)

    -12V 20mS (maximum)



    GENERAL SPECIFICATION


    • Efficiency:85%@ 20% load; 88%@ 50% load; 85%@ 100% load
    • PWOK Delay Time: 500ms > PWOK > 100ms
    • EMC Performance: EN55022 class B

    ENVIRONMENTAL SPECIFICATION


    • TEMP.Range: Storage Temperature: -20°C to + 70℃
    • MTBF: The power supply have a minimum predicted MTBF(MIL-HDBK-217) of 100,000 hours of continuous operation at 25℃, maximum-output load, and nominal AC inout voltage.


    Output Voltage and Current Rating


    +3.3V+5V+12V1-12V+5Vsb
    Ripple-Noise(R-P) mV50mV50mV120mV200mV50mV
    Regulation Load %±5%±5%±5%±10%±5%
    Output Max.(A)24A24A46A0.3A3A
    Output Min.(A)0.2A1A0.05A0A0A


    NOTES


    • +3.3V & +5V total output not exceed 130W.
    • When +5V is load to 24A, the +3.3V maximum load is 3A.
    • When +3.3V is load to 24A, the +5V maximum load is 10A.

    This content is subject to change, please refer to specification for more detail.
